Dynamic EFI

Bringing TBI and Multi Port Fuel Injection to a New Level.



Dynamic EFI is proud to provide the Embedded Lockers (EBL) system. Designed for use with GM TBI and MPFI systems it is a combination of an add in board, better code to run the engine, the What's Up Display, and documentation.

The EBL is a system designed to work together. It provides the user with the information, data, and tools to fine tune their engine.


The EBL Flash System, available now. . .

                   EBL Flash ECM


Highlights:
Click for more information about the EBL Flash system.




Announcements!

* New Product *

The TT-1 WB controller is available. This WB unit has been developed by the team here at Dynamic EFI. Designed for use with data logging equipment it provides two analog outputs along with a USB interface. A dedicated WB output and another output that can be a WB output or a simulated NB output. The WB output(s) are linear and fully user programmable for stoich and output voltage range. Provided with a sensor, USB cable, and the TT-1 WB Utility program. (click here).

* New Articles *

An Introduction to Tuning. How to use a calibration editor. How to program a new calibration to the EBL Flash ECM. Tuning Introduction, a must read.

* Additional Information *

Full wiring diagrams for the EBL Flash ECM. There are a few differences from the stock ECMs the EBL Flash replaces.These diagrams show the regular connections along with the additional functionality (click here).


The TT-1 WB

TT-1 WB
